Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other)

Vacuum Equipment » Vacuum Pad Series ZP3/ZP2/ZP - Select from Functions » With Buffer

Vacuum Pad Series ZP3/ZP2/ZP - Select from the Shape

Select from Functions : With Buffer

|Flat Pad

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer (ZP)	WEB Catalog
■For adsorption of general workpieces. ■For adsorption of work pieces with flat and not deformed surface.		U	Flat	ZP	φ2, φ4, φ6, φ8, φ10, φ13, φ16, φ20, φ25, φ32, φ40, φ50	●	●	detail
		U	Flat	ZP2	φ3, φ4	－	－	detail
		U	Flat	ZP3	φ1.5, φ3.5	●	●	detail
		MU	Flat	ZP2	φ2, φ3.5, φ4, φ5, φ6, φ8, φ10, φ15	●	-	detail
		EU	Flat	ZP2	φ2, φ4, φ6, φ8, φ15	●	-	detail
		AU	Flat	ZP2	φ2, φ3, φ4, φ6, φ8	-	-	detail

|Flat Pad with Rib

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For a workpiece which is likely to deform. ■For releasing a workpiece certainly.		C	Flat Pad with rib	ZP	φ10, φ13, φ16, φ20, φ25, φ32, φ40, φ50	●	●	detail
		C	Flat Pad with rib	ZP2	φ6, φ7, φ8	－	－	detail

|Flat Pad with Groove

		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For a workpiece which is likely to deform. ■For releasing a workpiece certainly.		UM	Flat with groove	ZP3	φ4, φ6, φ8, φ10, φ13, φ16	●	●	detail
■For adsorption of general workpieces. ■To be used when adsorption surface of the workpiece is flat and not deformed.		UM	Flat type with groove	ZP3E	φ32,φ40,φ50,φ63,φ80,φ100,φ125	●	●	detail

|Thin Flat Pad

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For a workpiece which is likely to deform.		UT	Thin flat	ZP	φ10, φ13, φ16	●	●	detail
■For a workpiece which is likely to deform.		UT	Thin flat	ZP2	φ5, φ6 φ11, φ14, φ18, φ20	－	－	detail

|Thin Flat Pad with Rib

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For a workpiece which is likely to deform. ■For releasing a workpiece certainly.		CT	Thin flat with rib	ZP	φ10, φ13, φ16	●	●	detail

|Bellows Pad

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For use where there is no space for the buffer (spring type). For adsorption of workpieces with inclined surface.		B	Bellows	ZP	φ6, φ8, φ10, φ13, φ16, φ20, φ25, φ32, φ40, φ50	●	●	detail
		B	Bellows	ZP2	φ6, φ8	－	－	detail
		B	Bellows	ZP3	φ4, φ6, φ8, φ10, φ13, φ16	●	●	detail
		J	Bellows (Multistage type)	ZP2	φ6, φ9, φ10, φ14, φ15, φ16, φ25, φ30	-	-	detail
		MB	Bellows	ZP2	φ4, φ6, φ8, φ10, φ15, φ20	●	-	detail
		ZJ	Bellows	ZP2	φ2, φ4, φ5, φ6, φ40, φ46	-	-	detail
		ZJ	4,5-Stage Bellows	ZP2	φ15,φ20,φ30,φ40,φ46	●	-	detail

|Deep Pad

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■To be used when work is curved shape.		D	Deep	ZP	φ10, φ16, φ25, φ40	●	●	detail

|Oval Pad

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For work pieces with limitations on the adsorption surface.		U	Oval	ZP	2×4, 3.5×7, 4×10	●	●	detail
		W	Oval	ZP2	3.5×7, 4×10, 4×20, 4×30, 5×10, 5×20, 5×30, 6×10, 6×20, 6×30, 8×20, 8×30	●	●	detail

|Heavy-duty Pad

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For heavy or large workpieces.		H	Heavy-duty (Flat with rib)	ZP	φ40, φ50, φ63, φ80, φ100, φ125	●	●	detail
		H	Heavy-duty (Thin flat with rib)	ZP2	φ32,φ300,φ340	－	－	detail
		HT	Heavy-duty (Thin flat with rib)	ZP2	φ150, φ250	－	－	detail
		HW	Heavy-duty (Oval)	ZP2	30×50	－	－	detail

|Heavy-duty Bellows Pad

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For heavy or large work pieces. ■For use where there is no space for the buffer (spring type). For adsorption of work pieces with inclined surface.		HB	Heavy-duty bellows	ZP	φ40, φ50, φ63, φ80, φ100, φ125	●	●	detail
		HB	Heavy-duty bellows	ZP2	φ32, φ150	－	－	detail

|Pad with Ball Spline Buffer

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■Ball spline guide is used to the buffer.		U	Flat	ZP2	φ2, φ4, φ6, φ8	●	●	detail

|Ball Joint Pad

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For adsorption of work pieces with inclined or curved surface.		F	Ball joint	ZP	φ10, φ13, φ16, φ20, φ25, φ32, φ40, φ50	●	●	detail

|Heavy-duty Ball Joint Pad

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For adsorption of work pieces with inclined or curved surface.		H	Heavy-duty ball joint (Flat with rib)	ZP2	φ40, φ50, φ63, φ80, φ100, φ125	●	●	detail
		HB	Heavy-duty ball joint (bellows)	ZP2	φ40, φ50, φ63, φ80, φ100, φ125	●	●	detail
