Vacuum Equipment » Vacuum Pad Series ZP3/ZP2/ZP - Select from the Workpieces » CD/DVD

Vacuum Pad Series ZP3/ZP2/ZP - Select from the Shape

Select from the Workpieces : CD/DVD

Precautions

Confirm if adsorption marks remain on the workpiece.
<When the workpiece and pad do not separate>
1. Consider reducing the vacuum pressure.
2. Consider revising the release air circuit.
3. Consider changing to a blast-type pad specification.
4. Consider reducing the pad diameter.

|Short-type Pad

Variations	Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■Space-saving in the height direction	MU	Flat	ZP2	φ2, φ3.5, φ4, φ5, φ6, φ8, φ10, φ15	●	－	detail
	EU	Flat	ZP2	φ2, φ4, φ6, φ8, φ15	●	－	detail
	AU	Flat	ZP2	φ2, φ3, φ4, φ6, φ8	－	－	detail

|Compact Pad

Variations	Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■Flat For adsorption of general workpieces. For adsorption of workpieces with flat and not deformed surface. ■Flat with rib For a workpiece which is likely to deform or for releasing a workpiece certainly. ■Thin flat For a workpiece which is likely to deform. ■Bellows For adsorption of workpieces with inclined surface,	U	Flat	ZP	φ2, φ4, φ6, φ8	●	●	detail
			ZP2	φ3, φ4	-	-	detail
			ZP3	φ1.5, φ3.5	●	●	detail
	C	Flat with rib	ZP2	φ6, φ7, φ8	-	-	detail
	UT	Thin flat	ZP2	φ5, φ6	-	-	detail
	B	Bellows	ZP	φ6, φ8	-	●	detail
			ZP2	φ6, φ8	-	-	detail
			ZP3	φ4, φ6, φ8	●	●	detail

|Flat Pad

Variations	Symbol	Type	Series	Pad diameter	Adapter type	Buffer (ZP)	WEB Catalog
■For adsorption of general workpieces. ■For adsorption of work pieces with flat and not deformed surface.	U	Flat	ZP	φ2, φ4, φ6, φ8, φ10, φ13, φ16, φ20, φ25, φ32, φ40, φ50	●	●	detail
	U	Flat	ZP2	φ3, φ4	－	－	detail
	U	Flat	ZP3	φ1.5, φ3.5	●	●	detail
	MU	Flat	ZP2	φ2, φ3.5, φ4, φ5, φ6, φ8, φ10, φ15	●	-	detail
	EU	Flat	ZP2	φ2, φ4, φ6, φ8, φ15	●	-	detail
	AU	Flat	ZP2	φ2, φ3, φ4, φ6, φ8	-	-	detail

|Flat Pad with Rib

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For a workpiece which is likely to deform. ■For releasing a workpiece certainly.		C	Flat Pad with rib	ZP	φ10, φ13, φ16, φ20, φ25, φ32, φ40, φ50	●	●	detail
		C	Flat Pad with rib	ZP2	φ6, φ7, φ8	－	－	detail

|Flat Pad with Groove

		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For a workpiece which is likely to deform. ■For releasing a workpiece certainly.		UM	Flat with groove	ZP3	φ4, φ6, φ8, φ10, φ13, φ16	●	●	detail
■For adsorption of general workpieces. ■To be used when adsorption surface of the workpiece is flat and not deformed.		UM	Flat type with groove	ZP3E	φ32,φ40,φ50,φ63,φ80,φ100,φ125	●	●	detail

|Thin Flat Pad

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For a workpiece which is likely to deform.		UT	Thin flat	ZP	φ10, φ13, φ16	●	●	detail
■For a workpiece which is likely to deform.		UT	Thin flat	ZP2	φ5, φ6 φ11, φ14, φ18, φ20	－	－	detail

|Thin Flat Pad with Rib

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For a workpiece which is likely to deform. ■For releasing a workpiece certainly.		CT	Thin flat with rib	ZP	φ10, φ13, φ16	●	●	detail

|Bellows Pad

Variations	Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For use where there is no space for the buffer (spring type). For adsorption of workpieces with inclined surface.	B	Bellows	ZP	φ6, φ8, φ10, φ13, φ16, φ20, φ25, φ32, φ40, φ50	●	●	detail
	B	Bellows	ZP2	φ6, φ8	－	－	detail
	B	Bellows	ZP3	φ4, φ6, φ8, φ10, φ13, φ16	●	●	detail
	J	Bellows (Multistage type)	ZP2	φ6, φ9, φ10, φ14, φ15, φ16, φ25, φ30	-	-	detail
	MB	Bellows	ZP2	φ4, φ6, φ8, φ10, φ15, φ20	●	-	detail
	ZJ	Bellows	ZP2	φ2, φ4, φ5, φ6, φ40, φ46	-	-	detail
	ZJ	4,5-Stage Bellows	ZP2	φ15,φ20,φ30,φ40,φ46	●	-	detail

|Blast-type Pad

Variations	Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■Blast treatment to create finely uneven surface for adsorption. Workpieces can be removed easily.	U	Flat	ZP2	φ4	-	-	detail
	C	Flat with rib	ZP2	φ6, φ8	-	-	detail
	UM	Flat with groove	ZP3	φ4,φ6,φ8,φ10,φ13,φ16	●	●	detail
	B	Bellows	ZP2	φ6, φ8	-	-	detail
	J	Bellows (Multistage type)	ZP2	φ10, φ15, φ25, φ30	-	-	detail
	MU	Flat	ZP2	φ2, φ3.5, φ4, φ5, φ6, φ8, φ10, φ15	●	-	detail
	EU	Flat	ZP2	φ2, φ4, φ6	●	-	detail
	MT	Thin flat (With groove)	ZP2	φ10, φ15, φ20, φ25, φ30	●	-	detail
	MB	Bellows	ZP2	φ4, φ6, φ8, φ10, φ15, φ20	●	-	detail

|Mark-free Pad

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For use where adsorption marks must not be left on workpieces.		U	Flat	ZP2	φ4, φ6, φ8, φ10, φ16, φ25, φ32, φ40, φ50	-	-	detail
		H	Heavy-duty (Flat with rib)	ZP2	φ40, φ50, φ63, φ80, φ100, φ125	-	-	detail

|Resin Attachment

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■Mark-free. ■Prevents sticking of the rubber and the workpieces.		K	Bellows	ZP2	φ6, φ8, φ10, φ13, φ16, φ20, φ25, φ32	-	-	detail

|Vacuum Pad for Transferring Disks

Variations		Symbol	Type	Series	Pad diameter	Adapter type	Buffer	WEB Catalog
■For adsorbing circular components like CD and DVD. ■Bellows mechanism is realized in the pad to dampen the impact to the work.		-	For transferring disks	ZP2	20×25 （ID×OD：PCD 22.5)	-	-	detail
